ILIA SURFACE LUMINAIRE

The ILIA™ luminaire family utilizes ALVA’s proprietary LED module technology to offer Designers a sleek, modern lighting option available in 23”, 34”, and 45.5”.

STANDARD FEATURES

  • Best-in-Class LM/W of 120 minimum (module)
  • ETL Damp Listed
  • 120-277V Input
  • Color Temperatures offered: 2700K, 000K, 3500K, 4000K
  • Includes 0-10V dimming and LumenSelect™ four light level output
  • 10 Year Warranty (excludes shade)
  • 100,000+ hours rated life time

SHADES

Resin

ALVA has developed eco-friendly proprietary shade options with embedded fabrics and/or custom designs in architectural resin (PETG)

RESIN SHADE PATTERN OPTIONS

RESIN SHADE STANDARD FEATURES

  • Ecologically friendly translucent resin
  • Evenly lit with no hot spots or lamp imaging
  • Excellent impact strength/chemical resistance
  • Exceptional transparency and clarity
  • 100% recyclable, 40% post-consumer recycled content
  • Easily cleaned using standard cleaning agents
  • Resin Shade carries a 5 Year Warranty



Acrylic

ALVA has selected a high-performance white opal acrylic developed specifically for LEDs.

ACRYLIC SHADE STANDARD FEATURES

  • Highest light output option
  • 85 LM/W with shade
  • Superior impact strength
  • Abrasion and fingerprint resistant
  • Lights beautifully
  • Matte finish
  • 10 Year Warranty

White Opal



SPECS

MODEL SHADE MATERIAL WIDTH HEIGHT EXTENSION WATTAGE INPUT DIMMING
ILIA 23 Architectural Resin 6.3″ 23" 4" 25.2W 120-277V 0-10V & LumenSelect™
ILIA 34 Architectural Resin 6.3″ 34" 4" 38W 120-277V 0-10V & LumenSelect™
ILIA 46 Architectural Resin 6.3″ 45.5" 4" 50.5W 120-278V 0-10V & LumenSelect™
ILIA 23 Acrylic 6.3″ 23" 4" 25.2W 120-279V 0-10V & LumenSelect™
ILIA 34
Acrylic 6.3″ 34"
4" 38W 120-280V 0-10V & LumenSelect™
ILIA 46
Acrylic 6.3″ 45.5" 4" 50.5W 120-282V 0-10V & LumenSelect™

IES

MODEL DESCRIPTION
ILIA-23
ILIA-23 with Architectural Resin shade
ILIA-34
ILIA-34 with Architectural Resin shade
ILIA-46
ILIA-46 with Architectural Resin shade
